TURKMENISTAN
TURKMENBASHY OIL REFINERY COMPLEX
UNLEADED CAR BENZENE
TŞ 05766698-28-2003 change,^
|
Description of index |
Figure for mark |
||
A-80 |
||||
1 |
Octane number. not less than -By motor method -By researcher method |
76,0 80,0 |
||
2 |
Actual resin concentration.mg 100sm3benzine not more than |
5,0 |
||
3 |
Induction period.min. not less than: |
360 |
||
4 |
Mass portion of sulfur, % not more than |
0,1 |
||
5 |
Copper plate testing |
ok |
||
6 |
Color |
From colorless before yellow |
||
7 |
Density 200C. kg|m3 |
No standard, determination necessary |
||
8 |
Saturated vapor pressure, kPa |
35-70 |
||
9 |
Mass portion of merkaptan sulfur, % not more than |
no standard |
||
10 |
Acidity , mg KOH by 100 sm3, not more than |
3,0 |
||
11 |
Fraction composition : -initial boiling point, 0C, not less than: - 10%-summer time - 10%-winter time - 50% - 90% - Final boiling point, oC, not more than: - Mass portion of residue in flask, %, (vol), not more than -Losses, %,(vol.), not more than |
35 80 75 120 190 215 2 4 |
||
12 |
Vapor stopper index, not more than -summer time - winter time |
950 1250 |
||
13 |
Presence of acids and bases, soluble in water |
no |
||
14 |
Presence of mechanical impurities and water |
no |
Note:
Winter time- from 1 October before 1 April
TURKMENISTAN
TURKMENBASHY OIL REFINERY COMPLEX
UNLEADED CAR BENZENE
TŞ 05766698-28-2003 change,^
|
Description of index |
Figure for mark |
||
A-92 |
||||
1 |
Octane number. not less than -By motor method -By researcher method |
82,5 92,0 |
||
2 |
Actual resin concentration.mg 100sm3benzine not more than |
5,0 |
||
3 |
Induction period.min. not less than: |
360 |
||
4 |
Mass portion of sulfur, % not more than |
0,1 |
||
5 |
Copper plate testing |
ok |
||
6 |
Color |
From colorless before yellow |
||
7 |
Density 200C. kg|m3 |
No standard, determination necessary |
||
8 |
Saturated vapor pressure, kPa |
35-70 |
||
9 |
Mass portion of merkaptan sulfur, % not more than |
no standard |
||
10 |
Acidity , mg KOH by 100 sm3, not more than |
3,0 |
||
11 |
Fraction composition : -initial boiling point, 0C, not less than: - 10%-summer time - 10%-winter time - 50% - 90% - Final boiling point, oC, not more than: - Mass portion of residue in flask, %, (vol), not more than -Losses, %,(vol.), not more than |
35 80 75 120 190 215 2 4 |
||
12 |
Vapor stopper index, not more than -summer time - winter time |
950 1250 |
||
13 |
Presence of acids and bases, soluble in water |
no |
||
14 |
Presence of mechanical impurities and water |
no |
Note:
Winter time- from 1 October before 1 April
“Approved“ by Acting chief engineer of Ahal Gas to Gasoline plant of SC “Turkmengas” /signature/ D. Ovezgeldiyev /seal: Ahal Gas to Gasoline plant of State Concern “Turkmengas”/
“04”03.2020
SC “TURKMENGAZ”
Production laboratory' of Ahal gas to gasoline plant
(full name of the laboratory)
Certificate of Attestation___________________ ____ ______ ________
(number and date of issue of certificate of accreditation (attestation))
Gasoline obtained from processing of natural gas brand ECO-93, party number 8, lot size 2400 tons 04.03.2020
Name and type of product supplied for examination, the date of the examination TDS-1233-2019 Gasoline obtained from processing of natural gas. Technical conditions Ahal gas to gasoline plant
(name of the individual or legal entity that provided the product for examination)
Sample position: 11-TKOl B
QUALITY PASSPORT No. 8
No. |
Name of indicators |
Standard name |
Standards |
Actually |
Regulator}' compliance |
1 |
Octane quantity, not less: |
Zeltex |
|
|
|
-checking method |
93 |
94.4 |
Conform |
||
-motor method |
83 |
82.9 |
Conform |
||
2 |
Lead concentration, mg / dm3, no more |
TDS-32350- 2014 |
5 |
- |
|
3 |
Density at 15 °C, kg / m3 |
ASTM D4052- 96 |
720.0-775.5 |
743.2 |
Conform |
4 |
Examination with a copper plate (3 hours at 50°C), scale unit |
ASTM D130- 94 |
1 class |
la |
Conform |
5 |
Weight fraction of sulfur,%, no more |
ASTM D5453- 93 |
0.0010 |
0.0001 |
Conform |
6 |
Concentration of actual resins, mg per 100 ml of gasoline, not more |
ASTMD381- 01 |
5 |
- |
|
7 |
Gasoline induction period, min, not less |
GOST- IS07536-15 |
360 |
- |
|
8 |
Volume fraction of benzene,%, no more |
TDS-ISO 22854-10 |
1.0 |
0.15 |
Conform |
9 |
Volume fraction of methanol,%, no more |
3.0 |
0 |
Conform |
|
10 |
Volume fraction of ethanol,%, no more |
5.0 |
0 |
Conform |
|
11 |
Weight fraction of oxygen,% |
2.7 |
- |
|
|
12 |
Manganese concentration, mg / dm3 |
TDS-33158- 2014 |
must not be |
- |
|
13 |
Amount in composition of hydrocarbons,% volume, not more -olefins -aromatic hydrocarbons |
TDS-ISO 22854-2016 |
18.0 35.0 |
9.59 31.3 |
Conform Conform
|
14 |
Cloud point, °C, not more |
T§- ASTM D25 00-11 |
-25 |
-25 does not grow cloudy |
Conform |
15 |
Appearance |
|
Clean, transparent |
Clean, transparent |
Conform |
16 |
Sanirated vapor pressure (Vapor pressure), kPa |
T§ -ASTM D5191-04a |
45-90 |
60 |
Conform |
17 |
Steam density index (IPP), no more |
TDS 12332019 cl.7.7 |
|
|
|
|
In summer |
950 |
- |
|
|
|
In winter |
1250 |
- |
|
|
18 |
Initial boiling point, °C, not less |
TDS-ISO 3405-2013 |
35 |
36.3 |
Conform |
|
Fractional boiling yield,% volume: |
|
|
|
|
|
70 °C |
22.0-50.0 |
27.9 |
Conform |
|
|
100 °C |
46.0-71.0 |
49.4 |
Conform |
|
|
150 °C, not less |
.75 |
75.2 |
Conform |
|
|
end of boiling. °C, not higher |
210 |
203.6 |
Conform |
|
|
volume fraction of sediment in the flask,%, not more |
2 |
1.1 |
Conform |
TURKMENISTAN
TURKMENBASHY OIL REFINERY COMPLEX
UNLEADED CAR BENZENE
TŞ 05766698-28-2003 change,^
|
Description of index |
Figure for mark |
||
A-95 |
||||
1 |
Octane number. not less than -By motor method -By researcher method |
85,0 95,0 |
||
2 |
Actual resin concentration.mg 100sm3benzine not more than |
5,0 |
||
3 |
Induction period.min. not less than: |
360 |
||
4 |
Mass portion of sulfur, % not more than |
0,05 |
||
5 |
Copper plate testing |
ok |
||
6 |
Color |
From colorless before yellow |
||
7 |
Density 200C. kg|m3 |
No standard, determination necessary |
||
8 |
Saturated vapor pressure, kPa |
35-70 |
||
9 |
Mass portion of merkaptan sulfur, % not more than |
no standard |
||
10 |
Acidity , mg KOH by 100 sm3, not more than |
3,0 |
||
11 |
Fraction composition : -initial boiling point, 0C, not less than: - 10%-summer time - 10%-winter time - 50% - 90% - Final boiling point, oC, not more than: - Mass portion of residue in flask, %, (vol), not more than -Losses, %,(vol.), not more than |
35 80 75 120 190 215 2 4 |
||
12 |
Vapor stopper index, not more than -summer time - winter time |
950 1250 |
||
13 |
Presence of acids and bases, soluble in water |
no |
||
14 |
Presence of mechanical impurities and water |
no |
Note:
Winter time- from 1 October before 1 April
